Works in workshop
Overhaul
Our workshop performs daily overhauls on different parts of industrial engines, and additionally Overhaul on them.
Today we show you the main steps to carry out an Overhaul on any of the industrial engines that RS Motor usually has in its facilities.
These engines operate mainly with natural gas, biogas or other types of gases. There are other industrial engines that RS Motor regularly overhauls, although in this case they are diesel engines.
What is the Overhaul of engines?
We define Overhaul as the complete disassembly of an industrial engine, either at RS Motor or at the customer’s premises, in order to then proceed with the examination of the disassembled parts, repair and/or recondition them, replace the spare parts susceptible to wear and finally reassemble the whole unit.
The reason for the overhaul is to make the engine ready to run another complete working cycle, which will depend on the engine manufacturer’s specifications.
When is an overhaul necessary?
Normally, the engine overhaul is defined according to the manufacturer’s maintenance plan, which recommends the hours of operation at which it should be carried out.
The interval is different if the engine is a DEUTZ, MWM (CAT), Jenbacher or Guascor for example.
If we are talking about DEUTZ/MWM (CAT) engines, the overhaul is usually carried out every 48,000 operating hours or 64,000 operating hours depending on the quality of the gas consumed by the engine. The higher the gas quality (natural gas), the longer the interval between overhauls. However, there are exceptions in the case of very recent engines, where the overhaul is marked at 80,000 operating hours if the gas quality is very good.
As far as Jenbacher engines are concerned, current engines are usually marked for overhaul at 60,000 hours of operation (whatever the type of gas they consume). Like DEUTZ/MWM (CAT), newly installed Jenbacher engines can have their overhaul extended to 80,000 operating hours.
Finally, in Guascor engines, the overhaul if the engine consumes biogas, is usually at 50,400 hours of operation while if it is running on natural gas, the intervention could take place at 60,000 hours.
Types of Overhaul
As a rule, an Overhaul is a complete maintenance of the engine, in which the wearing components of both the upper and lower parts of the engine are replaced. However, RS Motor is able to offer its customers various types of alternatives in order to minimise the impact of engine downtime on the power plant.
Sometimes, if the lead time is not important, the overhaul may be carried out at RS Motor’s facilities.
If lead time is a limiting factor, but not a major one, RS Motor will bring its team to the customer’s site to carry out the overhaul.
If the delivery time is critical, RS Motor will, if possible, provide the customer with an exchange shortblock or exchange longblock.
Finally, if the delivery time is most important, we would offer the possibility of supplying an exchange engine with the overhaul already done. This engine would be fully assembled and would be “plug & play”, so plant downtime would be minimal.
En ocasiones, si el plazo de entrega no es importante, el Overhaul podría realizarse en las instalaciones de RS Motor.
Si el plazo de entrega es un factor limitante, aunque no demasiado importante, RS Motor desplazaría a su equipo a las instalaciones del cliente para llevar a cabo el Overhaul.
Si el plazo de entrega es crítico, RS Motor pondría a disposición del cliente, siempre y cuando esto fuese posible, un “shortblock” de intercambio o un “longblock” de intercambio.
Por último, si el plazo de entrega es lo más importante, se ofrecería la posibilidad de suministrar un motor de intercambio con el Overhaul ya realizado. Este motor iría completamente ensamblado y sería “plug & play”, por lo que el tiempo de parada de la planta sería mínimo.
Request a quote
Customers all over the world already rely on RS Motor when they need to overhaul their industrial engines, whether gas or diesel.
Join them and ask us for availability and price if you want to try us. Currently we can say that we are the best alternative to the Official Service offered by the brand, since years of experience in workmanship and the supply and installation of genuine and/or OEM spare parts make this possible.
catalog
Looking for technical information about our services and products? Browse our catalog and discover the wide range of spare parts, components, and solutions that RS Motor offers you.
Find everything you need in one place, with the quality and reliability that define us.
Engine Refurbishment
List of Guascor Engines We Commonly Work On
The process of reconditioning comprises the disassembly of the mechanical part, analysis and verification of the condition, ultrasonic cleaning of mechanical elements, dimensional checks and/or hydraulic tests, replacement of wear elements and resetting of the reconditioned element to zero hours.
The elements that are usually reconditioned in the “RS Motor” workshop are:
- Actuators or speed controllers.
- Plate heat exchangers.
- Water pumps.
- Oil pumps.
- Starters.
- Crankpipes (check).
- Plug rods (check).
- Connecting rods (parallelism check and bushing replacement)
- Zero valves.
- Carburets.
- Jackets.
- Throttle valves.
- Alternators.
- Mixing valves or mixers.
- Fuel pumps.
- Tubers.
Request a quote
Marks of engines we work with
At RS Motor, we specialise in carrying out work and overhaul on the industrial engines listed below:
- TBG616V8
- TBG616V12
- TBG616V16
- TBG620V12
- TBG620V16
- TBG620V20
- TBG632V12
- TBG632V16
- TCG2016V8
- TCG2016V12
- TCG2016V16
- TCG2020V12
- TCG2020V16
- TCG2020V20
- TCG2032V12
- TCG2032V16
- CAT CG132-8
- CAT CG132-12
- CAT CG132-16
- CAT CG170-12
- CAT CG170-16
- CAT CG170-20
- CAT CG260-12
- CAT CG260-16
- TBD616V8
- TBD616V12
- TBD616V16
- TBD620V12
- TBD620V16
- TBD645L6
- TBD645L8
- TBD645L9
- TCD2016V8
- TCD2016V12
- TCD2016V16
- TBD640
- SVB628
- Jenbacher J208
- Jenbacher J212
- Jenbacher J312
- Jenbacher J316
- Jenbacher J320
- Jenbacher J412
- Jenbacher J416
- Jenbacher J420
- Jenbacher J612
- Jenbacher J616
- Jenbacher J620
- Jenbacher J624
GUASCOR/ SIEMENS
- FG 180 6L
- FGLD 180 6L
- SFGLD 180 LL
- FG 240 8L
- FGLD 240 8L
- SFGLD 240 8L
- HGM 240 8L
- FGLD 360 12V
- SFGLD 360 12V
- FGLD 480 16V
- SFGLD 480 16V
- SFGLD 560 16V
- SFGM 560 16V
- HGM 560 16V
Request a quote
Clients from various industries already trust RS Motor to carry out the complete overhaul of their industrial engines—both gas and diesel.
If you’re looking for a serious, efficient, and reliable alternative to the Official Service, get in touch with us. We’ll guide you through every step of the process and provide a customized offer tailored to your needs. At RS Motor, we combine years of technical experience with the use of genuine and/or OEM spare parts to ensure the best possible results.
